St215 motor + st205 gearbox into St165 JDM build

Talk about your project car here

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Thu Aug 09, 2012 8:09 am

Thanks for the comments guys :D Appreciate it. You've inspired me to get my ass into gear and get some more photos up! Check back soon!

Cheers
Members don't see the above ad. Register now - it's free!
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby ZeroDrift » Fri Aug 10, 2012 4:57 pm

bmt wrote:Thanks for the comments guys :D Appreciate it. You've inspired me to get my ass into gear and get some more photos up! Check back soon!

Cheers



Looking forward to see more pictures!
ZeroDrift
Club Member

Posts: 437
Joined: Tue Feb 16, 2010 4:18 pm
Location: Colorado

1988 Toyota Celica

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sat Aug 11, 2012 8:33 am

Took some pics today

My bumper with mesh in the holes.


Unfortunately it seems like the hot glue is not doing the job :doh: so I will have to readdress that problem!

This is my inlet side


Same thing looking down from above


The blowoff valve is adjustable from full recirculating to full atmosphere. I directed the recirculate back towards the turbo as a kind of cheap anti lag! I hope anyway. :twisted: The little container next to the Radiator cap is my custom overflow bottle.
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sat Aug 11, 2012 8:47 am

Onwards,

This is my down pipe looking from above


Looking from the side


Looking from underneath


So it's a 3" downpipe with a separated waste gate pipe that is 41mm, (1 5/8"). There is a divider in side so the exhaust is totally sealed from the waste gate side. I will probably send it out this week to get it ceramic coated.

More soon!
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Aug 12, 2012 2:43 am

More,

Down pipe out of the car


Downpipe showing divider

The divider pokes into the exhaust side of the turbo to separate the exhaust gases from the waste gate gases.
The "Mid" pipe

3" stainless all the way including the flex.
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Aug 12, 2012 2:56 am

Showing the mid pipe in the car


Looking up from underneath

I welded a little skid plate on to the cross member to protect my flex from scrape damage. They're
expensive!!
Fraser

This is what I build for a living. They are called a Fraser. They are a series 3 Lotus 7 replica. We build everything inhouse. It is my job to skin the cars in alloy.
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Aug 12, 2012 3:06 am

Bit more on my part on the Frasers. I know off topic but I thought you guys might be interested and yes we do export!!

Freshly skinned car

Everything is done by hand.

Rear of the car


This is the most labour intensive part of the car as all the curved parts have the alloy wrapped over the chassis tubes. LOTS of shrinking by hand with a hammer. My workmates hate me when it comes to this part of the skinning, bang bang bang for most of a day!
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby ZeroDrift » Mon Aug 13, 2012 2:52 pm

Exhaust and downpipe look great! Also great work on the Lotus Rep. I've had a ride in a Super 7 with a rotary engine in there and it was a fun little car.

Image The Miata was the Mrs' old car and we were out auto crossing.

Honestly I'd be interested in getting a downpipe and mid pipe from you if you ever decide to make a spare setup! Assuming it'd fit the stock turbo...
ZeroDrift
Club Member

Posts: 437
Joined: Tue Feb 16, 2010 4:18 pm
Location: Colorado

1988 Toyota Celica

Re: St215 motor + st205 gearbox into St165 JDM build

Postby GT4times2 » Mon Aug 13, 2012 9:09 pm

It's coming along quite nicely! Loving the work on the car. Glad to see ST165s under the knife.

ZeroDrift wrote:Honestly I'd be interested in getting a downpipe and mid pipe from you if you ever decide to make a spare setup! Assuming it'd fit the stock turbo...[/b]


Get it done locally. It's cheaper than having pipes shipped from NZ. Just saying... :|
Frantz
12 Toyota Sienna LE
12 Toyota Camry SE
90 ST185 (MRP) Gen4
90 ST185 (Gray) Not sure what gen yet.
88 ST165 Gen3-The works
89 ST165 Gen4-on the way
+ Many other projects, under covers....
GT4times2
Established Member

Posts: 2176
Joined: Mon Aug 23, 2004 3:21 pm
Location: Georgia

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Tue Aug 14, 2012 6:45 am

GT4times2 wrote:It's coming along quite nicely! Loving the work on the car. Glad to see ST165s under the knife.

ZeroDrift wrote:Honestly I'd be interested in getting a downpipe and mid pipe from you if you ever decide to make a spare setup! Assuming it'd fit the stock turbo...[/b]


Get it done locally. It's cheaper than having pipes shipped from NZ. Just saying... :|


Thanks guys. ^^^^Totally agree!! Support your local industry! Otherwise when you want it, it wont be there and wherever you have been going
can hold you to ransom.

Fitted a Whiteline sway bar tonight. Part number BTR29Z. Rear sway bar for a St185/St205, fits perfect if your St165 doesn't have the ABS bulge.
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Sep 23, 2012 9:28 am

Update! Surge tank



The other alloy plate is to cover the bigger hole that I cut out above the fuel tank. I can pull everything out of the tank without dropping the tank. I just thought it would be easier!

The High pressure pump


You can just see it poking out from behind the surge tank. So behind the surge tank and in the cavity above the wheel well is a prefilter from the surge tank into the high pressure pump then through a post filter and onto the motor.
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Sep 23, 2012 9:37 am

My down pipe came back from the coaters and it's on. Yay!

From underneath



From the side and underneath


Man these engine bays get full!!
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby bmt » Sun Sep 23, 2012 10:03 am

Oh I changed something.....

Before,



After,



Another view,



I just wanted something different. It came up on our version of ebay . If you dont know it's from a St162 Corona. I had the grille dechromed and painted it black as were the indicator lense surrounds. I saved a bunch of weight by getting rid of the pop up lights as a bonus.
I have plans for the bonnet including a colour change!!
Living the good life in New Zealand!!
bmt
Club Member

Posts: 201
Joined: Fri Feb 18, 2011 8:01 am

Re: St215 motor + st205 gearbox into St165 JDM build

Postby Rick89GTS » Sun Sep 23, 2012 2:06 pm

Great build. And I thought my stock 165 engine bay was tight! Nice headlight conversion. We don't get the ST162 Corona in North America, so it's not an option for us.
User avatar
Rick89GTS
GTFour God

Posts: 3778
Joined: Sun Aug 08, 2004 6:28 am
Location: Great White North, Canada

Re: St215 motor + st205 gearbox into St165 JDM build

Postby GT4times2 » Sun Sep 23, 2012 5:05 pm

bmt wrote:Oh I changed something.....

Before,



After,



Another view,



I just wanted something different. It came up on our version of ebay . If you dont know it's from a St162 Corona. I had the grille dechromed and painted it black as were the indicator lense surrounds. I saved a bunch of weight by getting rid of the pop up lights as a bonus.
I have plans for the bonnet including a colour change!!



Looks cool, although I prefer the pop up lights on the ST165. I always said, if I got a (88-89) Celica GTS coupe, I'd look for that front end conversion. Always keep the original in case you want to change. Keep up the good work.
Frantz
12 Toyota Sienna LE
12 Toyota Camry SE
90 ST185 (MRP) Gen4
90 ST185 (Gray) Not sure what gen yet.
88 ST165 Gen3-The works
89 ST165 Gen4-on the way
+ Many other projects, under covers....
GT4times2
Established Member

Posts: 2176
Joined: Mon Aug 23, 2004 3:21 pm
Location: Georgia
